DAP4CS allows you to use inexpensive diagnostic adapters and J2534 adapters with CarmanScan Auto-i application. The current version supports:

  • K+CAN Commander 1.4 and compatible
  • ELM327, vLinker (MIC331x/MIC3322)
  • Adapters on STN11xx/21xx (OBDLink, ELS27)
  • J2534 adapters (Scanmatik SM2-PRO,
    CHIPSOFT Pro, Tactrix OpenPort 2.0, etc.)

Most widely implemented protocols are supported, such as ISO 15765, KWP 2000, ISO 9141, SAE J1850 PWM/VPW, KWP 1281, VW TP 2.0. OEM protocols are also supported, such as Honda HDS, BMW TXD. Other OEM protocols such as Subaru SSM-1, Nissan Consult-1, Chrysler SCI, MMC SCI are supported with protocol-specific adapters based on FT232 chip or with some of J2534 adapters.

DAP4CS supports Hyundai/KIA SGW authorization.

You can use CarmanScan Auto-i & DAP4CS for reading/erasing diagnostic trouble codes, reading parameters and information from Control Units. Using CarmanScan Auto-i & DAP4CS for other procedures, such as adaptation, actuators test, injector coding, variant coding and so forth, is allowed only if you have an experience, knowledge and reference manuals for the procedures that you are going to do.

Please read DAP4CS installation notes.

You can download CarmanScan Auto-i application from the official CarmanScan web site.
Current version of DAP4CS supports version 2391 of Auto-i.
If you have problems downloading Auto-i application from the official website, then
you can find it here.
